• A silver and black electronic control panel featuring two toggle switches, a small power button, and a USB port, shown on a plain white background.
  • Instruction graphic showing a barcode label with a sample SN number and blue arrows pointing to text callouts explaining the model number and prefix requirements for switch replacement.
  • A recliner electronic control module with a gray and black casing, featuring two push-button switches and attached wiring including a red wire, a black cable, and a black connector with a blue band.
  • Top-down view of a control panel with labeled callout lines pointing to switch positions and a USB port. The panel has a silver outer housing, a black central frame, two gray toggle switches labeled Legrest Open and Legrest Close, a small light button, and a USB connector labeled Headrest Up and Headrest Down.
  • A black plastic dual USB-C charging panel with two silver USB-C connectors and a central power button, shown above a matching silver oval mounting frame on a white background.
  • A black electronic control module with a silver metal mounting bracket, a white barcode label, and two wires (black and red) coming out of the back, shown on a white background.
  • A black cable with a multi-pin circular connector on one end and a small black terminal block on the other, shown on a plain white background.
1 7

eMoMo HX90HULAN 5 Button Switch with Two Leads and USB

eMoMo HX90HULAN 5 Button Switch with Two Leads and USB

Shipping from China

$65.00 CAD
$65.00 CAD
Sale Sold out
Shipping calculated at checkout.

  • American Express
  • Apple Pay
  • Bancontact
  • Google Pay
  • iDEAL Wero
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
  • This is the genuine HX90HULAN switch, featuring 5 buttons, and utilizing a 5-pin male connector and a 2-pin rectangular connector. Suitable for a power recliner with 2 motors.
  • This switch is for the right-side armrest when facing the chair.

Compatibility

  • This unit is a sub-model of the HX90 series, with the full model HX90HULAN. It is not cross-compatible with other HX90 sub-models.
  • To confirm compatibility, take off your current switch from the armrest and check the serial number on its barcode sticker. Order this switch only if your serial number meets all the following criteria:
  • Prefix: Must begin with SN:E, SN:WT, or SN:ZE.
  • Model Code: The digits immediately following the prefix must be 90HULAN.
  • Check Digit: The character directly after "90HULAN "  must be a number or the letter V.

Features:

  • 5 Buttons:
    • 2 buttons for legrest open/close
    • 2 buttons for headrest tilt
    • The small button in the center is a multi-function button: click to turn on/off light strip; hold it to reset the chair.
  • USB port: 5V 2.1A output for charging mobile devices.
  • Two leads & connectors:
    • 5-pin male connector connects to the footrest motor
    • 2-pin rectangular connector connects to the base LED light

Package includes:

  • HX90HULAN switch x1
  • Face plate x1
  • Screws x2
